KQ-16W-R Double-sided automatic steel plate bevelling machine
Specification Model: KQ-16W-R
Total power: 1500W
Feeding speed：2.0~2.5m/min
Clamping plate thickness: 8~40mm
Bevelling angle：25~±45°
Bevel width: 0~22mm
Description
marker
Product Details
KQ-16W-R double-sided automatic steel plate beveling machine is a double-sided beveling machine designed and developed for customers with double-sided beveling processing needs, no need to turn over the plate, turn the machine head can be processed under the bevel, the use of the knife plate rolling shear extrusion type principle of work, cold cutting without deformation and no oxidation, equipped with 1500W high energy-efficiency motors, for you to save 50% of the consumption of electricity, can be processed carbon steel, manganese steel, aluminum alloy and other metal plate It can process V/Y bevel and K/X bevel of carbon steel, manganese steel, aluminum alloy and other metal plates.
| KQ-16W-R Technical Parameters | |
| power supply：AC380V 50Hz | Bevel angle：25~±45° |
| total power：1500W | Single Bevel Width：14mm |
| Feed rate：2.0-2.5m/min | Diameter of cutter plate：115mm |
| Clamping plate thickness：8-40mm | Bevel width：0-22mm |
| Clamping plate width：≥120mm | Number of blades：1pcs |
| Processing plate length：≥200mm | net weight：280Kg |
Advantages of KQ-16W-R double-sided automatic steel plate bevelling machine
1. Rolling shear principle, cold cutting without deformation and oxidation, beveling directly for welding.
2. The beveling angle is adjustable between 25~±45°.
3. Double-sided bevel processing, KQ-16W-R beveling machine without flap, turn the head can be processed under the bevel.
4. Fast beveling speed, up to 2.5m/min.
5. Spring shock absorbing design, automatically adjust the machine body lifting and lowering, adapt to the ground and plate undulation.
6. Helical gear reducer, stable performance.
7. Electrical integration, overload protection, economic and energy saving.
8. No sparks and flying dust, easy and neat operation.
9. It can process K/X/Y/V bevel of carbon steel, manganese steel, aluminum alloy and other metal plates.
10. Widely used in for steel structure, pressure vessel, engineering machinery, machining shipbuilding, metallurgy, electric power tower, petrochemical, wind power generation and other welding and cutting manufacturing fields.
