SKF-15 Portable Chamfering Machine
Specification Model: SKF-15
Total power：1100W
Spindle speed：2870r/min
Machining speed：1~3m/min
Bevelling angle: 30~60°
Bevel width: 3~15mm
Description
marker
Product Details
SKF-15 portable flat beveling machine, the body weighs only 23kg, designed for plate beveling and chamfering, is a convenient and dexterous hand-propelled beveling machine. There is no restriction on the length, width and thickness of the steel plate when processing bevels, so it can bevel narrow and thin plates, and it is also a multifunctional beveling machine, which can process bevels of square pipes and round pipes. It is suitable for deburring and chamfering of various metal materials before welding.
|
SKF-15 Technical Parameters |
|
| power supply：AC380V 50Hz | total power：1100W |
| Motor speed：2870r/min | Beveling speed：1000-3000mm/min |
| Bevel angle：30°-60° | Bevel width：3-15mm |
| Angle/bevel width：60°/10mm，45°/15mm，30°/12mm | |
| Operating noise：≤85dB | net weight：18Kg |
Advantages of SKF-15 portable chamfering machine
1. Cold cutting, no deformation, no oxidization of the bevel, first-class welding seam standard.
2. Light weight, low vibration, suitable for indoor and outdoor or limited site operation.
3. Ergonomic handle, labor-saving control.
4. Guiding roller, smooth and easy to push.
5. Combination of two butterfly-shaped milling cutter disk, 4-prong indexable inserts, 12 embedded four-pronged edge milling cutter blade cutting bevel.
6. Angle scale and thickness scale are clearly marked, 30°-60° adjustable.
7. Meet the K, V, X, Y type bevel processing, suitable for cast iron, carbon steel, aluminum and other metal plate bevel processing.
8. Optional pipe clamping auxiliaries, can bevel pipe ends.
